Have a durable Motor high-quality wear-resistant sleeve bearing motor which can continually work for 8000 hours, quiet and stable.
Have an overheat Protection System and easy to operate in both directions. Exhausts outward, Air inward and stop
Product details
Performance parameter
PRODUCTION INFORMATION
Have a durable Motor high-quality wear-resistant sleeve bearing motor which can continually work for 8000 hours, quiet and stable.
Have an overheat Protection System and easy to operate in both directions. Exhausts outward, Air inward and stop
Easy to install – Shall be wall/window mountable, predominantly to be used for Kitchen and bathroom, and shall come with universal three-pin plug and 1.5-meter long cable.
Main technical parameters
| Model No. | Rated Voltage | Frequency | Power | Wind | Noise |
| RBPT12-13C5 | 220V | 50HZ | 20W | 2.0m³/min | ≤35dB |
| RBPT12-13C1 | 220V | 50HZ | 20W | 2.0m³/min | ≤35dB |
| RBPT12-14B4 | 220V | 50HZ | 22W | 2.5m³/min | ≤42dB |
| RBPT12-15B3 | 220V | 50HZ | 28W | 7.0m³/min | ≤50dB |
| RBPT12-A1 | 220V | 50HZ | 33W | 5.0m³/min | ≤56dB |
| RBPT12-A2 | 220V | 50HZ | 33W | 5.0m³/min | ≤56dB |
| RBPT12-S3 | 220V | 50HZ | 18W | 3.0m³/min | ≤56dB |
Installation Dimension mm
| Model No. | Hole dimension | Mounting screw distance | Panel Size | Space Height | Pipe Size |
| RBPT12-13C5 | 204 | 222 | 250 | 165 | φ100 |
| RBPT12-13C1 | 204 | 222 | 250 | 165 | φ100 |
| RBPT12-14B4 | 230 | 240 | 270 | 170 | φ100 |
| RBPT12-15B3 | 310 | 240 | 365 | 170 | φ100 |
| RBPT12-A1 | 300 | 300 | |||
| RBPT12-A2 | 300 | 300 | |||
| RBPT12-S3 | 210 | 210 |
