M Type extension cable connector
M Type extension cable connector
M Type extension cable connector

M Type extension cable connector

Material: Nylon VO Class

Seal: Dingqing Rubber

IP Rate: IP68/1P69K

Environment temperature: static  state-40°℃----100°℃, dynamic state-20°℃---80°℃

Share:

Performance parameter

Material: Nylon VO Class

Seal: Dingqing Rubber

IP Rate: IP68/1P69K

Environment temperature: static  state-40°℃----100°℃, dynamic state-20°℃---80°℃

Colour: Grey, Black, white or other colour

Material: Nylon PA/UL94-V0

Seal: NBR

Protection class: IP68/1P69k(the wire should be in clamping range, and use O-rings.)

Temperature range: -40°C to 100°C in static state, -20°℃ to 80°C in dynamic state.

Color: Grey, black, white, other colors customized


M Type extension cable connector


ThreadCable range(mm)AG(mm)GL(mm)Spanner Size(mm)
M12*1.53-6.512.01518/15
M12*1.54-812.01518/19
M14*1.54-814.01522/19
M16*1.54-816.01522/19
M16*1.55-1016.01522/22
M18*1.55-1018.01524/22
M20*1.56-1220.01527/27
M22*1.510-1422.01527/27
M24*1.510-1424.01527/27
M25*1.511-1525.01530/30
M25*1.513-1825.01533/33
